What is ObjectDCL?

ObjectDCL is an enabling technology that was first introduced in 2001. It had a rebirth in a new product launch in mid-2007.

ObjectDCL allows drawing dialog boxes in AutoCAD®, easily and with more control than ever before. Configuration tabs can even be added to the AutoCAD® Options/Preferences dialog.

With ObjectDCL, the days of creating dialog boxes with the time consuming and confusing language of DCL are over. From now on dialogs are drawn quicker, easier and better. ObjectDCL provides more visual components and more customization options than were possible before with DCL.

What once took hours or even days to create can now be drawn in minutes. ObjectDCL includes all the dialog box styles and all the grid controls.

Intelligent Help

ObjectDCL provides an intelligent built-in help system that provides contextual information about a dialog box or a control.

Easy to use

Unlike AutoCAD®'s DCL, ObjectDCL is easy to use and creates dialogs effortlessly.

ObjectDCL extension for AutoCAD®

Here are the characteristics of the most recent release of the extension as well as reasons for taking advantage of what it has to offer:

• Compatible with dialog boxes created with previous releases of the ObjectDCL editor.
• Existing assets remain intact and don't loose value as no conversion is required.
• Compatible with a large range of AutoCAD® releases for all main occidental locales.



  Release	Supported
  AutoCAD® 2004	Yes
  AutoCAD® 2005	Yes
  AutoCAD® 2006	Yes
  AutoCAD® 2007	Yes
  AutoCAD® 2008	Yes
  AutoCAD® 2008 64 bits	Yes
  AutoCAD® 2009	Yes
  AutoCAD® 2009 64 bits	Yes

• Compatible with major Windows releases.



  Release	Supported
  Windows 2000	Yes
  Windows XP	Yes
  Windows 2003	Yes
  Windows Vista	Yes
  Windows XP 64 bits	Yes
  Windows 2003 64 bits	Yes
  Windows Vista 64 bits	Yes

• Unprecedented stability: existing software assets and resources are protected while operating on AutoCAD.
• Greatly improved reliability.
• Detailed error messages and debugging options.

The software development rests on world-class processes of software engineering and is assured by senior developers. We know how important it is to customers to perform in highly competitive markets, and that it requires a firm grip and the right tools. Today's era is about efficiency as well as effectiveness in meeting challenges and ensuring the growth of organizations.
